WARN Electric Heavy Weight Series Winch 16.5ti - 7480 kg 12V incl. HD-Steel Roller Fairled

Only on special order, delivery time 2 to 3 months

Highest capacity, most technologically advanced winch for big trucks

The 16.5ti features the full diagnostic ability of WARN thermometric technology, plus the extreme sealing, durability, and reliability that the WARN ti-series of winches are known for. Series-wound motor combined with a 3-stage planetary geartrain delivers 16,500 lbs. of pulling power. Thermometric indicator LED provides operator feedback on motor temperature.

With a rated line pull of 7840kg it is the perfect choice for large off-road vehicles and Trucks.

Includes:

• Solenoid Control Pack
• 3,7 m remote control cable (6 pin plug)
• Remote switch, with LED indicator
• with LED motor thermometric indicator
• High gloss, chip-resistant black powder coat
  finish over a massive cast-aluminum alloy housing
• Motor-mounted thermal sensor relays
• roller fairlead
• Rope-way clutch
• Steel cable with safety hook
• Battery cable: 1.83 m
• CE conformity confirmation
• German manual

Specifications:

• Motor: 12V, 4,66 PS Gen II, Series Wound
• control: Solenoid Control Pack
• Rated line pull: 7480 kg
• Operation: 3.7 m cable remote control
• Geartrain: 3-stage planetary gear
• Gear reduction ratio: 315: 1
• Brake: automatically
• Drum Size: 210 x 90 mm
• Cable supplied: 27 m x 11 mm
• Cable Window: HD-Steel roller fairlead
• Mounting bolt pattern: 254 mm x 114,3 mm
• Dimensions: L x D x H = 615 x 216 x 247 mm
• Finish: High-gloss powder coat over primer undercoating
• Weight: 63 kg
• CE marking

A brand product by Warn Industries

Performance Specifications:

Winching Manual English / Français / Español:
